The vertical twin rotor unmanned helicopter DZS-08 has a compact structure, high stability, good wind resistance, low requirements for flight sites, and can quickly adapt to diverse mission needs. It is widely used in emergency rescue, forest firefighting, power operations and other fields.
Product Features
Compact structure: The rotor and fuselage are small in size, making it easy to transport
High stability: longitudinal twin rotor design for more stable flight
Strong wind resistance: able to take off and land in strong winds, with good adaptability
Long endurance with high payload capacity: Strong load-bearing capacity and long endurance
Product details
The DZS-08 unmanned helicopter adopts a longitudinal configuration and a three blade design. This unique structural layout allows it to have smaller rotor and fuselage dimensions and a more compact overall structure under the same takeoff weight. This design not only greatly improves the stability of the helicopter, reduces the requirements for the flight site, and enables it to easily adapt to various complex environments, whether it is narrow urban blocks or rugged mountainous areas, it can quickly carry out operations, demonstrating extremely high flexibility and adaptability. Meanwhile, the compact structure also makes the helicopter more convenient during transportation, greatly improving the efficiency of task execution.
In terms of flight performance, the DZS-08 unmanned helicopter has strong wind resistance and can stably take off, land and cruise in strong wind environments, which greatly improves its operational ability in adverse weather conditions and provides reliable support for emergency rescue and other tasks. Its flight control system has rich and advanced functions, supporting multiple intelligent flight modes such as one click takeoff/landing, autonomous cruise, mission termination and recovery. Operators can easily control the helicopter's flight status through simple commands, greatly reducing operational difficulty and improving flight safety and reliability.
The payload and endurance capabilities of the DZS-08 unmanned helicopter are equally impressive. It has strong load-bearing capacity and can carry a large amount of materials or equipment to meet the needs of different mission scenarios. Whether it is the delivery of firefighting supplies during forest fire prevention or the transportation of personnel and supplies during emergency rescue, DZS-08 can easily handle it. At the same time, its excellent endurance enables it to operate continuously in the air for a long time, greatly improving the efficiency and range of task execution, reducing delays caused by frequent battery replacement or refueling, and providing strong support for long-term continuous operations.
In terms of communication system, the DZS-08 unmanned helicopter is equipped with advanced communication equipment to ensure stable communication with the ground control station. It has a long communication distance and can achieve long-distance flight control and data transmission, allowing operators to monitor the status of the drone in real time, send control instructions, monitor the status of task equipment, etc. Even in complex terrain and environments, it can maintain precise control of the helicopter. In addition, DZS-08 also supports external data links and satellite communication, further expanding its communication capabilities and application scope, enabling it to play an important role in a wider range of regions and more complex tasks.
The DZS-08 unmanned helicopter also has complete system maintenance and upkeep functions. It can record important data such as engine driving time and cumulative flight time, providing accurate time references for system maintenance. It helps operators to timely understand the usage status of the helicopter, arrange maintenance work in advance, ensure that the helicopter is always in good working condition, extend its service life, and reduce usage costs.
The DZS-08 longitudinal twin rotor unmanned helicopter has become an outstanding product in the field of unmanned helicopters due to its compact structure, high stability, strong wind resistance, long endurance, stable communication, and convenient maintenance. It has broad application prospects in many fields, such as forest fire prevention, emergency rescue, and material delivery, providing strong technical support and strong guarantees for the development of related industries. With the continuous advancement of technology and the expansion of applications, the DZS-08 unmanned helicopter will undoubtedly play a more important role in the future unmanned flight field, making greater contributions to people's lives and the development of society.
Technical Parameter
DZS-08 technical Parameter |
|
size |
4000*1300*1900mm |
weight |
340kg |
fuel tank |
80L |
Maximum takeoff weight |
650kg |
Load capacity (including oil) |
≤260kg |
endurance |
2-4 hours (maximum 10 hours) |
Ceiling |
Altitude 6500m |
Maximum flight speed |
160km/h |
cruising speed |
140km/h |
power |
gasoline |
rotor diameter |
480cm |
Wind loading |
≤ Level 7 |
The above parameters are for reference only. Detailed product parameters are subject to actual delivery. |
